900-Series Brush Flail Shredder

Description

The Vrisimo 900 Brush Flail Shredder is a dual-drive shredder designed to pulverize brush up to 5 inches thick. It will quickly reduce orchard and vineyard trimmings to mulch. Comes standard with internal wear liners and an internal re-cutter bar. Cutting capacity .5-5”.

Triple Flail Knives: Reversible triple knife 2.25-pound side slicer knives plus a 2-pound straight knife provide 7 pounds of knives in each station adding power and extra cutting surface.
Toughness: Severe duty design, high HP components.
Wear Liners Standard: Made of abrasion-resistant material.
True Shaft Technology: An electronically balanced cutter drum with serviceable hubs to ensure straight shafts that run smooth for years of reliable, vibration-free operation.
Adjustable Cutting Heights: Adjustable rear wheels and pick-up tines.
Adjustable Hitch:
The center of this machine is an electronically balanced 10-inch diameter, by 1/2” thick cutter drum and uses our triple knife 2.25-pound side slicer knives plus a 2-pound straight knife. Internal wear liners and a re-cutter bar are standard. All drive components including gearbox, belts and PTO shafts are 250 HP rated. Height adjustment is controlled hydraulically for continuous brush shredding as close to the ground as possible.
s-900-7 s-900-8 s-900-9
Cutting Width 7′ 8′ 9′
Overall Width 8.58′ 9.58′ 10.58′
Weight 3175 lbs. 3350 lbs. 3515 lbs.
Number of Knives 56 68 72
Height Adjustment 0-12″ 0-12″ 0-12″
Input PTO Speed 540 540 540
Gearbox Rating 250 HP 250 HP 250 HP
HP Requirement 80 90 100
Cutter Drum Speed 1850 rpm 1850 rpm 1850 rpm
